XT90 Battery Connectors Male Female Pair

The XT60 ensures a solid high-amp connection, perfect for applications up to and beyond 65A constant. XT60, Designed by Amass to be more reliable and a better quality connection than Deans T-Connectors. There is no patent on the XT60 connector, we hope this product is sold everywhere in the world and dominates the market, reducing customers dependency on the over-priced Deans T-connector. Say ‘No’ to the Deans Connector profiteers, and use XT-60’s!
IMPORTANT
These are not cheap copy XT60 plugs. These original Nylon XT60 plugs can handle over 60A current for extended periods without exceeding 80DegC thanks to their better contact surface area. The plug is also less likely to deform or melt in comparison to copied non-Nylon XT60 plugs.
Features:
•         Mechanical mounting for cable
•         Electrical mounting soldered
•         Contact plating Gold flash
•         Spatial Orientation Straight
•         Compatible for Wire size up to 12AWG
SPECIFICATION
Manufacturer
AMASS
Connector Type
XT60H
Gender
Female,Male
No. of Pins
2
Flammability Rating
UL94V-0
Contact Material
Brass
Body Material
polyamide
Color
Yellow
Rated Current(A)
60
Rated Operating Voltage
500V
Operating Temperature Range
-20 ~ 120°C
* Product Images are shown for illustrative purposes only and may differ from actual product.
